[제품사양]

• 주파수 응답특성 : 20Hz-20kHz±0.5Db; 1Hz-65kHz-3dB
• 왜율 : Less than 0.07%
• 채널밸런스 : Within 1dB
• 채널분리도 : Better than 60dB@1 kHz any input
• 크로스토크 : Better than 80dB@1 kHz
• 위상 : Non-inverting for all inputs and outputs
• 프리아웃 : PRE OUT 1and PRE OUT 2: Output Impedance l00Ω Maximum Output>7.3V RMS
• 헤드폰 출력 : Output impedance: 330Ω(Suitable for headphones 8Ω-2kΩ impedance)
• 녹음 출력 : VIDEO OUT,TAPE 1 OUT, TAPE2 OUT:Output impedance: 1kΩ Gain from input to record output 0dB(x1)
• 뮤팅회로 : Muting controlled manually or automatically
• 작동온도 : 10-35℃
• 정격전압 : 50-60Hz 100V, 110-120V and 220-230V models available Maximum Power Consumption: 440VA
• 크기 : 445x74x335 mm - including feet, terminals and controls 445x64x302 mm - excluding feet, terminals and controls
• 무게 : Net: 7.4kg; Shipping: 8.8kg
