Phono section

Gain @ 1 kHz RCA         Adjustable 39,8 – 71,4 dB

Gain @ 1 kHz XLR          Adjustable 45,8 – 76,4 dB

Resistance loading (RL)    Adjustable 10 Ω – 47 kΩ

Capacitive loading (CL)    Adjustable 0 – 350 pF

Maximum output level:    17.5 V rms (+ 25 dB V)

Overload margin > 31 dB @ 1 kHz

Output impedance         100 Ω single-ended, 200 Ω balanced

Frequency response       20 – 20 kHz +/- 0.2 dB

RIAA Correction Accuracy   ± 0,1 dB

Subsonic filter    -3dB @ 11 Hz, 24 dB/octave

Channel separation        > 85 dB, 20 – 20 kHz

THD + Noise      < 0.003 % @ 1 kHz

S/N-R    96 dB, 1 kHz, A-weighted, ref. 10 dB V output

S/N-R    91 dB, 1 kHz, A-weighted, ref. 5 mV input

S/N-R    67.4 dB, 1 kHz, A-weighted, ref. 500 μV input

Dimensions

Width   470 mm / 18.5 inches

Depth   373 mm / 14.6 inches

Height   78 mm / 3 inches

Weight  9 kg. / 19.8 lbs.
