-Type : Solid State
-Configuration Dual-Mono / Fully Balanced
-Power Supply Transformers 2 x 10VA (audio); 1 x 10VA (controller)
-Power Supply Capacitance 44,000
-Circuit Topology Open Loop
-Balanced Inputs (XLR) 2 Pairs
-Single-ended inputs (RCA) 4 pairs
-Input Impedance 22,000 Ohms
-Input Sensitivity 200mV - 4.0V RMS
-Monitor Loop 1
-Balanced Outputs (XLR) 1 Pair
-Single-ended Outputs (RCA) 2 Pairs (variable & fixed)
-Output Impedance 50 Ohms
-Volume Steps 1 dB from 0-30 and 0.5dB from 30-80
-Gain control M-eVOL (R-2R)
-Gain 9dB
-Signal-to-noise Ratio (20Hz - 20KHz) 115dB
-Maximum Output Voltage - XLR 12 Volts
-Maximum Output Voltage - RCA 6 Volts
-Frequency Response 5Hz - 100KHz (+0 / -0.1dB)
-Crosstalk @ 1KHz - 115dB
-IMD unmeasurable
-THD (20Hz - 20KHz) 0.002%
-12 Volt Trigger Output Operation
-Direct Logic (0V = off, 12V = on) Using a 3.5mm Mono microphone jack with an input impedance of 1000 Ohms and current requirement of 12mA
-Simlink Port 1 input + 1 output each on 1/8" mini-jack
-RS-232 Port 9-pin Female DB connector
-IR input 1/8" mini-jack
-Remote Control All-Aluminum Full Function
-Display Type 8 character dot matrix LED
-Power Consumption @ idle 20 Watts
-Fuse Replacement - 230V 0.5A short slow blow
-Dimension - Preamp (W x H x D) 18.75 x 4 x 16.5 in.
-Dimension - Controller / Power Supply 18.75 x 5.5 x 16.5 in.
-Shipping Weight 40 lbs / 18 Kgs
